Get Oil Cooler scientificly

Please insert the column below, then computer will calculate the most suitable product for you.








After calculation, you need minimum heat dissipation area of cooler is m2.
Therefore,
  • DT series, we recommend you use or above grade.
  • OR series, we recommend you use or above grade.
  • Sorry, according to the result, we can not find the products you demand.
    Please check the input is correct, or call：86-21-39907216

DT Series

A
C
D
E
G
H
J
K
L
M
N
P
Q
R
S
T



OR Series

A
B
C
D
E
F
G
　

　
Model A C D E G H J K L M N P Q R S T Max Flow (L/min) Cooling area (m2)
DT-303 299 48 147 117 95 79 35 15 128 75 11×20 75 120 89 1 ¾ 100 0.3
DT-304 370 48 219 189 95 79 35 15 128 75 11×20 75 120 89 1 ¾ 100 0.4
DT-305 468 48 291 261 95 79 35 15 128 75 11×20 75 120 89 1 ¾ 100 0.5
DT-307 608 48 435 465 95 79 35 15 128 75 11×20 75 120 89 1 ¾ 100 0.7
DT-309 758 48 578 548 95 79 35 15 128 75 11×20 75 120 89 1 ¾ 100 0.9
DT-311 898 48 722 692 95 79 35 15 128 75 11×20 75 120 89 1 ¾ 100 1.1
DT-411 620 70 425 384 100 88 35 15 150 105 11×20 93 140 114 1¼ ¾ 200 1.1
DT-415 770 70 568 528 100 88 35 15 150 105 11×20 93 140 114 1¼ ¾ 200 1.5
DT-418 910 70 712 672 100 88 35 15 150 105 11×20 93 140 114 1¼ ¾ 200 1.8
DT-421 1055 70 856 816 100 88 35 15 150 105 11×20 93 140 114 1¼ ¾ 200 2.1
DT-424 1220 70 1020 980 100 88 35 15 150 105 11×20 93 140 114 1¼ ¾ 200 2.4
DT-522 785 85 558 528 115 95 45 20 175 122 14×22 108 170 139 1½ ¾ 300 2.2
DT-527 925 85 702 672 115 95 45 20 175 122 14×22 108 170 139 1½ ¾ 300 2.7
DT-531 1070 85 846 816 115 95 45 20 175 122 14×22 108 170 139 1½ ¾ 300 3.1
DT-535 1235 85 1010 980 115 95 45 20 175 122 14×22 108 170 139 1½ ¾ 300 3.5
DT-544 1455 85 1228 1196 115 95 45 20 175 122 14×22 108 170 139 1½ ¾ 300 4.4
DT-649 1078 85 836 756 125 105 45 20 204 149 14×22 121 196 165 2 1 400 4.9
DT-657 1242 85 1000 920 125 105 45 20 204 149 14×22 121 196 165 2 1 400 5.7
DT-668 1462 85 1218 1138 125 105 45 20 204 149 14×22 121 196 165 2 1 400 6.8
DT-682 1742 85 1500 1420 125 105 45 20 204 149 14×22 121 196 165 2 1 400 8.2
DT-8107 1140 110 825 760 130 183 50 25 338 233 14×20 145 270 216 2 1¼ 600 10.7
DT-8125 1305 110 990 1025 130 183 50 25 338 233 14×20 145 270 216 2 1¼ 600 12.5
DT-8149 1520 110 1210 1130 130 183 50 25 338 233 14×20 145 270 216 2 1¼ 600 14.9
DT-8180 1805 110 1490 1420 130 183 50 25 338 233 14×20 145 270 216 2 1¼ 600 18.0
DT-10169 1100 173 800 725 150 222 38 15 210 152 14 223 293 267 10KV 2½
flange		 2 800 16.9
DT-10185 1210 173 910 835 150 222 38 15 210 152 14 223 293 267 10KV 2½
flange		 2 800 18.5
DT-10197 1300 173 980 905 150 222 38 15 210 152 14 223 293 267 10KV 2½
flange		 2 800 19.7
DT-10235 1500 173 1200 1125 150 222 38 15 210 152 14 223 293 267 10KV 2½
flange		 2 800 23.5
DT-10285 1775 173 1500 1425 150 222 38 15 210 152 14 223 293 267 10KV 2½
flange		 2 800 28.5
Model A B C D E F G Radiating pipe Cooling area m2 Capacity of tank Weight kg Flow of pump L/min Water flow L/min
OR-60 465 295 40 89.1 120 ¾ ¾ 22 0.24 60 8 100 50
OR-100 540 370 55 114.3 140 ¾ ¾ 26 0.35 100 12 200 100
OR-150 580 375 65 139.8 170 1¼ ¾ 42 0.6 150 15 300 150
OR-250 800 600 65 139.8 170 1¼ ¾ 58 1.2 250 22 300 150
OR-350 1205 1000 65 139.8 170 1¼ ¾ 58 1.9 350 30 300 150
OR-600 1225 970 85 165.2 196 2 1½ 58 1.9 600 40 400 200
OR-800 1725 1470 85 165.2 196 2 1½ 58 2.8 800 50 400 200
OR-1000 2140 1890 85 165.2 196 2 1½ 58 3.5 1000 60 400 200
OR-1200 2520 2270 85 165.2 196 2 1½ 58 4.2 1200 70 400 200
